BFC8117 EXPLOSION-PROTECTED LED FLOODLIGHT

Slots provide gas and water dissipationSlots help to increase pad bite and improve air circulationDrilled Holes and Slots create an escape route for debris, dust, gases, and waterSlots clean and de-gl...

Operating temperature: -20 ºC to +40 ºC
Rated voltage: AC220V-240V 50Hz/60Hz
Wattage: 150W 200W 400W 800W
Type: LED3030
Luminous efficiency: 140 lm / W
Degree of protection: IP66
Corrosion-proof class: WF2

CONTACT NOW down load to pdf

Product Details

Product Tags

APPLICATIONS
Suitable for large area illumination of hazardous locations in Zone 2, outdoor operations, construction sites and facilities, etc.

TECHNICAL DATA
Body material：Aluminum alloy with epoxy powder coating
Diffuser：Tempered glass
Rated voltage：220 V - 240 V AC 50 Hz / 60 Hz
Wattage：150 W / 200 W / 400 W
Luminous efficiency：140 lm / W
Degree of protection：IP65
Cable entry：G3/4
Corrosion-proof class：WF2

FEATURES
1、Suitable for Zone 1 applications
2、Degree of protection: IP 66
3、 LED light source providing high luminous efficacy and long service life
4、Designed with a dimmer interface (DC 0 - 10 V)
5、Multiple mounting options such as seat mounting, wall mounting and ceiling mounting
