BFC8115A EXPLOSION-PROTECTED LED FLOODLIGHT

Fixed calipers by Wilwood offer unmatched stopping power. The pistons in fixed calipers are located on both sides of the disc, allowing for evenly distributed clamping force. They apply more squeezing...

Operating temperature: -20 ºC to +40 ºC
Rated voltage: AC220V-240V 50Hz/60Hz
Wattage: 100W 150W 200W 400W 600W
Type: LED3030
Luminous efficiency: 140 lm / W
Degree of protection: IP66
Corrosion-proof class: WF2

CONTACT NOW down load to pdf

Product Details

Product Tags

APPLICATIONS
1、Suitable for illumination of hazardous locations designated as Zone 2 where ignitable gases are present.
2、Designed to illuminate roads in chemical and petrochemical plants, refineries and other process industries where ignitable gases are present.

TECHNICAL DATA
Body material：Aluminum alloy with epoxy powder coating
Diffuser：Tempered glass
Rated voltage：220 V - 240 V AC 50 Hz / 60 Hz
Wattage：50 W / 100 W
Luminous efficiency：140 lm / W
Degree of protection：IP65
Cable entry：G3/4
Corrosion-proof class：WF2

FEATURES
1、Designed to use in Zone 2 and Zone 21
2、LED light source providing high luminous efficacy and long life
3、Optional diffuser available
4、Multiple mounting options
5、Superior vibration resistance
6、Degree of protection up to IP65
